[PTFE] ANSI/ASME Flanged Rubber Bellow

[PTFE] ANSI/ASME Flanged Rubber Bellow

Shanghai Songjiang Group Introduce to you: ANSI/ASME Flanged Rubber Bellows lined with PTFE can be used in strong acid and alkali environments. It plays an important role in chemical piping and acid industry. Following are detailed introduction.



Generally, customers know that ordinary ANSI/ASME Flanged Rubber Bellows are suitable for normal temperature water below 80 degrees, and EPDM ANSI/ASME Flanged Rubber Bellows can be used for weak acid, weak base and high temperature media below 140 degrees. Nitrile rubber is suitable for hydraulic oil and oil and other oil-bearing media, but some corrosion resistance and high temperature medium ANSI/ASME Flanged Rubber Bellows simply cannot withstand, will quickly damage the internal structure of the ANSI/ASME Flanged Rubber Bellows and damage the ANSI/ASME Flanged Rubber Bellows. At this time, we must add a layer of strong acid and corrosion resistant material, polytetrafluoron, to the inner rubber layer of the ANSI/ASME Flanged Rubber Bellow (we call the ANSI/ASME Flanged Rubber Bellow with PTFE lining).

ANSI/ASME Flanged Rubber Bellows lined with PTFE can be used in strong acid and alkali environments.

Flexible ANSI/ASME Flanged Rubber Bellows lined with PTFE, also known as internal PTFE soft connections, are characterized by vibration reduction, high temperature resistance, flexibility and friction resistance. Suitable for pipe dislocation, displacement, dimensional change and vibration parts connection. It can be used as inlet and outlet pipe for storage tanks, tank trucks and other equipment, as well as other special purposes. It has a wide range of applications and more comprehensive functions. Ptfe of fluorine ANSI/ASME Flanged Rubber Bellow has excellent chemical stability and corrosion resistance. It is one of the best corrosion-resistant materials in the world. It can withstand all the other chemicals besides molten sodium and liquid fluorine. It will not boil in aqua regia. From the perspective of variation, it is widely used in a variety of acid, base and organic solvents. Sealing, high lubrication, non-stick, electrical insulation, good aging resistance, excellent temperature resistance (can work at 250°C to -180°C for a long time). Fluorine ANSI/ASME Flanged Rubber Bellow is suitable for pipe connection of various media. The ANSI/ASME Flanged Rubber Bellow lined with PTFE has good acid and alkali resistance and corrosion resistance. It can be used in a variety of strong acid and alkali and other media pipelines. It plays an important role in some chemical piping and acid industry.
