[Double Sphere] ANSI/ASME Flanged Rubber Bellow

[Double Sphere] ANSI/ASME Flanged Rubber Bellow

Product Name：Double Sphere ANSI/ASME Flanged Rubber Bellow
Material: EPDM, NBR, NR, Silicon，PTFE Lined
Pressure: PN6,PN10,PN16,PN25
Connection: DIN2576, BS4504 PN16, JIS10K, ANSI B16.47 150# Flange; BSP,NPT Thread





Main parameters of Double Sphere ANSI/ASME Flanged Rubber Bellow
Product model: KXT-F type
Nominal diameter: DN40-DN600mm
Inches: 1in to 24in
Product length: 155mm-330mm
Axial compression: 25mm-35mm
Axial stretch: 40mm-60mm
Lateral displacement: 40mm-35mm
Offset angle: 40 degrees – 30 degrees
Working pressure: 0.6Mpa, 1.0Mpa, 1.6Mpa
Product certification: ISO9001-2015
Inner and outer lining: NR, NBR, FKM, EPDM, PTFE，CR
Main frame: Nylon cord （Nylon 6）
Booster ring: multi-strand steel wire

Applications
Pumps
Chillers
Air compressors
HVAC equipment
Power generation
Electrical transformers
Motors

Compared with the single sphere, the double sphere has a larger compensation amount. Due to the good comprehensive performance of the double sphere, it is widely used in drainage, construction, petrochemical, HVAC, fire protection, electric power, light and heavy industry and other basic projects. It is especially suitable for pipelines with large vibration and frequent hot and cold changes. The models of double spheres are DN40-DN600mm, and the pressure models are 10-25kg.

On some pumping equipment with high vibration frequency and high noise, Use Double Sphere pipeline expansion joint, the increase in product length effectively ensures a good sound insulation effect and vibaration reduction performance!
